MODEL 7133 PITCHER TEE
The Shurjoint pitcher tee provides a quick and easy connection and transition from a grooved riser system to a screwed and flanged hydrant valve outlet. The pitcher tee is designed for 3”, 4” or 6” (88.9 mm, 114.3 mm or 165.1 mm O.D.) steel pipe risers with a 2½” BSP taper threaded or 3” grooved hydrant connection outlet.
- Easy installation with two grooved couplings.
- Easy positioning of the outlet direction.
- Reduces total installed cost.
- LPCB approved.
Shurjoint Model 7133 pressure ratings conform to the working pressure of the coupling used to join the system.

|
