MODEL 7181 UNIVERSAL REDUCING FLANGE ADAPTER
The Model 7181 Universal Reducing Flange Adapter provides for a rigid transition between a flanged piping system and a one or two-size reduced grooved system without the use of a concentric reducer. The flange drilling can mate to ANSI 125/150, PN10/16, BS-10E and JIS 10K.
Shurjoint Model 7181 pressure ratings conform to the working pressure of the coupling used to join the system.
|
