MODEL BH-22C BRASS SWING CHECK VALVE

Grooved-end, Spring Loaded Clapper

The Shurjoint Model BH-22C swing check valve is designed for grooved inlet and outlet connections, featuring a brass body with spring-loaded clapper with rubber seat, rated 250 psi (17 bar) working water pressure and suitable for installation in the horizontal or vertical position (upward flow only). The valve body, end piece and clapper are made of brass castings per ASTM A-584 copper alloy C85700. For installation in Shurjoint’s copper system, use Model C307 transition coupling.

*Working pressure is based on connection with roll- or cut-grooved standard wall carbon steel pipe.
